200CC UTV Challenger 200EX Dune Buggy Go kart Off Road 2 Seater Auto CVT EFI

UTV CHALLENGER  200EX 200CC
Features:

• 200cc air cool engine EPA
• Electronic Fuel Injection(EFI,not a carby system)
• Adjustable Driver Padded seat with 4 Point safety harness
• Adjustable steering wheel(low-high)-Adjustable pinion rack Controls
• Hydraulic front and rear disc brakes
• Electric key start with kill switch
• Auto with the reverse gear
• Digital dash / LED Headlights / Light-bar / Indicators / Horn
• Adjustable speed governor behind the pedal
• Bigger 10 inch knobby wheel tyres with Alloy rims
• Double A arm independent suspension
• Ball joint independent rear suspension
• 2WD-rear chain driving
• Front bull bar / Luggage rack / Tow bar/Windscreen/ adjustable rear view mirrors
• Side nets for extra safety, a bikini sunshade top
• Front steel bumper
• Sunshade top canopy
• Adjustable side rearview mirrors
• Turn led indicator lights
• Trailer hitch
• Parking brake
• Ergonomic steering wheel
• Individual sport seats
• Large rear utility cab
• Windscreen

Color: Blue, Red  Please ask for availability .

Specifications

Buggy dimensions: 2500x1260x1600mm LxWxH

Packing size: 2300x1330x880mm LxWxH

Net/gross weight: 300kgs/335kgs

Max loading: 247kgs

Front wheel centre distance: 1080mm

Rear wheel centre distance: 985mm

Min ground clearance: 160mm

Max speed: 60km/h

Engine model: 161QMK-A  4-stroke, single cylinder

Displacement: 200cc

Bore x Stroke: 61mm x 57.8mm

Compression ratio:   8.8:1

Fuel supply method: EFI

Power: 8kw/7500RPM 14hp

Torque:15N.M/5000RPM

Ignition mode: battery ignition

Start mode: electric start

Lubrication mode: splash

Spark plug model: C7HSA

crankcase lubrication oil model: SAE 10W/40

Fuel tank capacity: 8L

Transmission mode: CVT

Gearbox: Built-in reverse

Clutch: Auto

Battery model: YTX12-BS 12V10AH

Fuse:15A

Front and rear wheels: 22x7-10, 22x10-10 with Alloy rims

Tyre pressure:15psi

Front suspension method: double A arm independent suspension

Rear suspension: Rear axle with double A and double shock absorbers

Driven mode: rear wheel chain driven

Climbing ability: 15-20 degrees

Max Carry cab loading：100kgs

Shipping cost:

Please send me your postcode/suburb then we will quote a shipping rate asap. Most items will be sent to your local depot. Home delivery will cause an extra fee.

Assembly:

This buggy comes in a crate, assembly requests. Please install wheels/mudguard/seats/top roll cage, etc. Vihicles are shpped to you in a carton.95% assembled. Customer must:

Un-crate

Perform initial vehicle setup

Perform engine oil service

Check and adjust all systems, throttle, brakes.

Check and tighten all bolts/nuts

Perform break-in after one hour of opration

By customer's mechanic at customer's expense

If you need an assembly and we will charge $300 extra, assembly service is available for local pickup customers.

Warranty

The Manufacturer warranty DOES NOT COVER REPAIRS.The manufacturer warranty covers parts only and the labor is not covered under any circumstances.Any damaged or missing delivery items will be replaced.The warranty does not cover repairs or damage due to operation.
